Dải đo độ ẩm/ nhiệt độ

 10 to 95% r.h. / 0 to 60°C

Độ phân dải độ ẩm/ nhiệt độ

1% r.h. / 1°C

Cấp chính xác độ ẩm/ nhiệt độ

 ±2% r.h. / 1°C

Khoảng cách đo

50m

Kiểu cảm biến độ ẩm/nhiệt độ

  điện dung/ PT1000

thời gian phản hồi

4 giây

Chiều dai cáp (từ cảm biến đến màn hình hiển thị

1 m

Màn hình hiển thị

100mm high LED (hiển thị giá trị Luôn phiên )

Cổng kết nối

RS-232

nguồn

230V / 50 to 60Hz

Kích thước

Sensor: 50 x 70 x 20mm
Display: 175 x 250 x 75mm

Cấp bảo vệ

IP 54

Trọng lượng

1.3kg (Với cảm biến và cáp)

  Humidity detector to measure relative humidity and temperature,
with a large display visible from up to 50m distance

The PCE-G1 humidity detector has been designed for measuring relative humidity and temperature, with readings shown on its high visibility display. The humidity detector is composed of a 100mm high LED and comes with IP54. This humidity detector has a display will alternate values and show relative humidity for 2 seconds followed by temperature for 2 seconds. The sensor comes calibrated from the manufacturer. An optional ISO calibration and certification can be ordered separately. Easy to use, accurate and durable.

PCE-G1 humidity detector: Image of temperature being displayed.

Image of temperature being displayed.

PCE-G1 humidity detector: Image of humidity being displayed.

Image of humidity being displayed.

PCE-G1 humidity detector: the PCE-G1 taking a measurement

The image shows the display installed in an warehouse. The measurement values can be seen at a distance of up to 50m away. The display connects to the combined sensor using a 1m long cable. The sensor (capacitive / PT1000) can be recalibrated and is housed in ABS plastic. Readings are displayed alternatively every two seconds.

View or print the user's manual
PCE-G1 humidity detector: the user's manual

Technical specifications

Measurement ranges
relative humidity / temperature


10 to 95% r.h. / 0 to 60°C

Resolution
relative humidity / temperature


1% r.h. / 1°C

Accuracy
relative humidity / temperature


 ±2% r.h. / 1°C

Visible distance

can be read from 50m away

Sensor type
relative humidity / temperature


capacitive / PT1000

Response time T90

approx. 4 seconds

Cable length (between sensor and display)

1 detector

Display

100mm high LED (alternates values)

Port

RS-232

Power

230V / 50 to 60Hz

Dimensions

Sensor: 50 x 70 x 20mm
Display: 175 x 250 x 75mm

Protection

IP 54

Weight

1.3kg (with sensor and cable)

Contents
PCE-G1 humidity detector, display, sensor connecting cable 1m long), mains adaptor and user's manual.
