Technical Specifications
|
||
| DCV | Maximum Voltage: | 1000V |
| Accuracy: | Fluke 88 V: ±(0.1%+1) | |
| Best Resolution: | Fluke 88 V: 0.01 mV | |
| ACV | Maximum Voltage: | 1000V |
| Accuracy: | Fluke 88 V: ±(0.5%+2) | |
| AC Bandwidth: | Fluke 88 V: 5kHz | |
| Best Resolution: | 0.01 mV | |
| DC Current | Maximum Amps: | 10A |
| Amps Accuracy: | Fluke 88 V: ±(0.4%+2) | |
| Best Resolution: | Fluke 88 V: 0.001 mA | |
| AC Current | Maximum Amps: | 10A |
| Amps Accuracy: | Fluke 88 V: ±(1.2%+2) | |
| Best Resolution: | 0.001 mA | |
| Resistance | Maximum Resistance: | 50 MΩ |
| Accuracy: | Fluke 88 V: ±(0.4%+1) | |
| Best Resolution: | 0.1Ω | |
| Capacitance | Maximum Capacitance: | 9,999 µF |
| Accuracy: | ±(1%+2) | |
| Best Resolution: | 0.01 nF | |
| Frequency | Maximum Frequency: | 200 KHz |
| Accuracy: | ±(0.005%+1) | |
| Best Resolution: | 0.01 Hz | |
| Duty Cycle | Maximum Duty Cycle: | 99.9 % |
| Accuracy: | within 2% per KHz +0.1% | |
| Best Resolution: | 0.1 % | |
| Temperature Measurement | -200.0°C - 1090°C | |
| -328.0°F - 1994.0°F, 1.0% excluding probe | ||
| 80 BK Temperature Probe | -40 °C - 260 °C | |
| -40 °F - 500 °F, 2.2 °C or 2% whichever is greater | ||
| Conductance | Maximum Conductance: | 60.00 nS |
| Accuracy: | ±(1.0%+10) | |
| Maximum Resolution: | 0.01 nS | |
| Operating Range | Operating Temperature: | -20 °C - 55 °C |
| Storage Temperature: | -40 °C - 60 °C | |
| Physical | 5.2 cm x 9.8cm x 20.1 cm (2.06” x 3.86” x 7.93”) | |
| 624 g (22 oz.) | ||
| Included Accessories | 88V/A AUTOMOTIVE KIT; | 88V, TL224 silicone test leads, AC285 long reach alligator clips, TP220 test probes, RPM 80 inductive RPM pick-up, magnet and strap, 80BK temperature probe, two automotive backprobe pins, insulation piercing probe, C800 durable carrying case, holster, 9V battery (installed), Getting Started Manual, and CD with detailed manual. |
